One Stop Service Standard FR4 Prototype PCB Assembly

Product Categories
Shenzhen Jingbang Technology Co. , Ltd
Contact Now

One Stop Service Standard FR4 Prototype PCB Assembly

  • 1
  • 2
  • 3

Brand Name : FASTPCBA

Model Number : One-Stop PCB Assembly

Certification : IATF16949, ISO13485, ISO9001

Place of Origin : China

MOQ : 1pcs

Price : 1

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 150000 Pieces per Month

Delivery Time : 5

Packaging Details : PCB: Vacuum Packing/ PCBA: ESD Packing

Sercive : PCB and SMT assembly with one-stop service

Number of layers : 1-48

Material : FR4, High TG FR4, High Frequency, Alum, FPC

PCB outline : Square,circle,irregular(with jigs)

Min space : 0.075mm

Max size of finish board : 700*460mm

Contact Now

Standard Prototype Fr4 PCB Assembly Manufacturer With One Stop Service

PCB Capability

Article Description Capability
Material Laminate materials FR4, High TG FR4, High Frequency, Alum, FPC...
Board Cutting Number of layers 1-48
Min.thickness for inner layers
(Cu thickness are excluded)		 0.003”(0.07mm)
Board Thickness Standard (0.1-4mm±10%)
Min. Single/Double:0.008±0.004”
4layer:0.01±0.008”
8layer:0.01±0.008”
Bow and twist no more than 7/1000
Copper Weight Outer Cu weight 0.5-4 0z
Inner Cu weight 0.5-3 0z
Drilling Min size 0.0078”(0.2mm)
Drill deviation ±0.002″(0.05mm)
PTH hole tolerance ±0.002″(0.005mm)
NPTH hole tolerance ±0.002″(0.005mm)
Solder Mask Color Green,white,black,red,blue…
Min solder mask clearanace 0.003″(0.07mm)
Thickness (0.012*0.017mm)
Silkscreen Color white,black,yellow,blue…
Min size 0.006″(0.15mm)
Max Size of Finish Board 700*460mm
Surface Finish HASL,ENIG,immersion silver,immersion tin,OSP…
PCB Outline Square,circle,irregular(with jigs)
Package QFN,BGA,SSOP,PLCC,LGA

One Stop Service Standard FR4 Prototype PCB Assembly

FASTPCBA is famous for high precisions pcb manufacturing and assembly service around the world. Especially military, automotive, medical, industrial, smart home, communication, aerospace electronic pcba customers prefer to cooperate with us.

One Stop Service Standard FR4 Prototype PCB Assembly

Standard Prototype Fr4 PCB Assembly Manufacturer With One Stop Service

FASTPCBA is the high tech pcba factory in shenzhen china over 20 years, our pcba service feature: middle and small batch quick pcb prototype, turnkey pcb assembly, high quality custom made pcb manufacturing, original package components procurements etc.

One Stop Service Standard FR4 Prototype PCB Assembly

With complete dust free & esd protection smt workshop, FASTPCBA has win trust and support from domestic and abroad customers of automotive, medical, industrial control etc. All pcba products here abide by ISO9001 & ISO13485 & ISO14000 &IATF16949 certificates, reliable and stable pcb manufacturing and assembly service are assured.

One Stop Service Standard FR4 Prototype PCB Assembly

FASTPCBA believes quality derives from profession, reputation wins the future. From grass-roots employees to senior management all concentrate on precise and high quality pcba solutions to provide better service for customers.

One Stop Service Standard FR4 Prototype PCB Assembly
